Prodcut Name:CRH Series

Code: 1368683924 Price:0

Product Description

Shaft mm	Bearing Model		Overall dimensionsmm
	Basic type	Sealed	Overall dimensionsmm
	Basic type	Sealed	d1	D	C	B1
6.35	CRH 8-1VB	CRH 8-1VBUU	6.35	12.7	9.525	26.194
6.35	CRH 9 VB	CRH 9 VBUU	6.35	14.288	9.525	26.194
7.938	CRH 10-1 VB	CRH 10-1 VBUU	7.938	15.875	11.112	30.956
7.938	CRH 11VB	CRH 11VBUU	7.938	17.462	11.112	30.956
11.112	CRH 12VB	CRH 12VBUU	11.112	19.05	12.7	35.719
11.112	CRH 14VB	CRH 14VBUU	11.112	22.225	12.7	35.719
15.875	CRH 16VB	CRH 16VBUU	15.875	25.4	15.875	42.069
15.875	CRH 18VB	CRH 18VBUU	15.875	28.575	15.875	42.069
19.05	CRH 20VB	CRH 20VBUU	19.05	31.75	19.05	51.594
19.05	CRH 22VB	CRH 22VBUU	19.05	34.925	19.05	51.594
22.225	CRH 24VB	CRH 24VBUU	22.225	38.1	22.225	61.119
22.225	CRH 26VB	CRH 26VBUU	22.225	41.275	22.225	61.119
25.4	CRH 28VB	CRH 28VBUU	25.4	44.45	25.4	70.644
25.4	CRH 30VB	CRH 30VBUU	25.4	47.625	25.4	70.644
28.575	CRH 32VB	CRH 32VBUU	28.575	50.8	31.75	63.344
28.575	CRH 36VB	CRH 36VBUU	28.575	57.15	31.75	63.344
31.75	CRH 40VB	CRH 40VBUU	31.75	63.5	38.1	96.044
31.75	CRH 44VB	CRH 44VBUU	31.75	69.85	38.1	96.044
