Location:Index--->Product Center >> Yoke type track rollers >> RNA22...2RS NA22...2RS Series

Prodcut Name:RNA22...2RS NA22...2RS Series

Code: 1368682963 Price:0

Product Description

structure

Shaft
Diameter

Bearing Designation

Boundary Dimensions

Basic Load Rating

Limiting Speed

Without IR

Mass

With IR

Mass

d

Fw

D

B

C

Dynamic

Static

Oil

mm

g

g

mm

N

rpm

19	RNA22/6 2RS	18	NA22/6 2RS	22	6	10	19	12	11.8	5000	4350	18000
19	RNA22/6 2RSX	18	NA22/6 2RSX	22	6	10	19	12	11.8	5000	4350	18000
24	RNA22/8 2RS	29	NA22/8 2RS	34	8	12	24	12	11.8	5500	5200	14000
24	RNA22/8 2RSX	29	NA22/6 2RSX	34	8	12	24	12	11.8	5500	5200	14000
30	RNA2200 2RS	52	NA2200 2RS	60	10	14	30	14	13.8	7600	8100	11000
30	RNA2200 2RSX	52	NA2200 2RSX	60	10	14	30	14	13.8	7600	8100	11000
32	RNA2201 2RS	57	NA2201 2RS	67	12	16	32	14	13.8	8500	9700	9500
32	RNA2201 2RSX	57	NA2201 2RSX	67	12	16	32	14	13.8	8500	9700	9500
35	RNA2202 2RS	60	NA2202 2RS	75	15	20	35	14	13.8	9600	12000	7000
35	RNA2202 2RSX	60	NA2202 2RSX	75	15	20	35	14	13.8	9600	12000	7000
40	RNA2203 2RS	94	NA2203 2RS	112	17	22	40	16	15.8	12000	16500	6000
40	RNA2203 2RSX	94	NA2203 2RSX	112	17	22	40	16	15.8	12000	16500	6000
47	RNA2204 2RS	152	NA2204 2RS	177	20	25	47	18	17.8	18500	21900	4600
47	RNA2204 2RSX	152	NA2204 2RSX	177	20	25	47	18	17.8	18500	21900	4600
52	RNA2205 2RS	179	NA2205 2RS	209	25	30	52	18	17.8	20100	26000	3500
52	RNA2205 2RSX	179	NA2205 2RSX	209	25	30	52	18	17.8	20100	26000	3500
62	RNA2206 2RS	284	NA2206 2RS	324	30	35	62	20	19.8	23000	28000	2800
62	RNA2206 2RSX	284	NA2206 2RSX	324	30	35	62	20	19.8	23000	28000	2800
72	RNA2207 2RS	432	NA2207 2RS	505	35	42	72	23	22.7	29800	46300	2200
72	RNA2207 2RSX	432	NA2207 2RSX	505	35	42	72	23	22.7	29800	46300	2200
80	RNA2208 2RS	530	NA2208 2RS	628	40	48	80	23	22.7	38200	57700	1700
80	RNA2208 2RSX	530	NA2208 2RSX	628	40	48	80	23	22.7	38200	57700	1700
85	RNA2209 2RS	545	NA2209 2RS	655	45	52	85	23	22.7	40300	63800	1600
85	RNA2209 2RSX	545	NA2209 2RSX	655	45	52	85	23	22.7	40300	63800	1600
90	RNA22010 2RS	563	NA22010 2RS	690	50	58	90	23	22.7	66000	86000	1300
90	RNA22010 2RSX	563	NA22010 2RSX	690	50	58	90	23	22.7	66000	86000	1300
