Prodcut Name:UCFLX00

Code: 1369090671 Price:0

Bearing Unit NO.	Shaft Dia d		Dimensions(mm)										Bolt Used		Bearing No.	Housing No.	Housing Wt (kg)
Bearing Unit NO.	(in)	(mm)	a	e	i	g	l	s	b	z	Bi	n	(in)	(mm)	Bearing No.	Housing No.	Housing Wt (kg)
UCFLX05-13 UCFLX05-14 UCFLX05-15 UCFLX05-16 UCFLX05	13/16 7/8 15/16 1	25	141	117	18	13	30	12	83	40.2	38.1	15.9	3/8	M10	UCX05-13 UCX05-14 UCX05-15 UCX05-16 UCX05	FLX05	0.61
UCFLX06-17 UCFLX06-18 UCFLX06-19 UCFLX06-20 UCFLX06	1-1/16 1-1/8 1-3/16 1-1/4	30	156	130	19	14	34	16	95	44.4	42.9	17.5	1/2	M14	UCX06-17 UCX06-18 UCX06-19 UCX06-20 UCX06	FLX06	0.82
UCFLX07-20 UCFLX07-21 UCFLX07-22 UCFLX07-23 UCFLX07	1-1/4 1-5/16 1-3/8 1-7/16	35	171	144	21	14	38	16	105	51.2	49.2	19	1/2	M14	UCX07-20 UCX07-21 UCX07-22 UCX07-23 UCX07	FLX07	1.31
UCFLX08-24 UCFLX08-25 UCFLX08	1-1/2 1-9/16	40	179	148	22	14	40	16	111	52.2	49.2	19	1/2	M14	UCX08-24 UCX08-25 UCX08	FLX08	1.27
UCFLX09-26 UCFLX09-27 UCFLX09-28 UCFLX09	1-5/8 1-11/16 1-3/4	45	189	157	23	14	40	16	116	55.6	51.6	19	1/2	M14	UCX09-26 UCX09-27 UCX09-28 UCX09	FLX09	1.4
UCFLX10-29 UCFLX10-30 UCFLX10-31 UCFLX10-32 UCFLX10	1-13/16 1-7/8 1-15/16 2	50	216	184	26	20	44	19	133	59.4	55.6	22.2	5/8	M16	UCX10-29 UCX10-30 UCX10-31 UCX10-32 UCX10	FLX10	2.05
