Prodcut Name:6200 Series

Code: 1368941186 Price:0

Product Description

Bearing	main dimension(mm)					basic load rating(kgf)		rotational speed(rpm)			Weight
No .	Bore	O.D.	Width	Chamfer		Dynamic	Static	Greese		Oil	(KG)
	d	D	B	r/min		Ce	Co	Z.ZZ	RS.2RS	Z
								RU.2RU	RS.2RS	Z
6200	10	30	9	0.6		520	245	24000	15000	29000	0.032
6201	12	32	10	0.6		690	310	22000	13000	27000	0.037
6202	15	35	11	0.6		780	380	20000	12000	24000	0.045
6203	17	40	12	0.6		975	490	17000	10000	21000	0.065
6204	20	47	14	1		1310	680	15000	8700	17000	0.106
6205	25	52	15	1		1430	800	13000	7700	15000	0.128
6206	30	62	16	1		1980	1150	11000	6400	13000	0.199
6207	35	72	17	1.1		2620	1570	9200	5500	11000	0.288
6208	40	80	18	1.1		2970	1820	8300	5000	10000	0.366
6209	45	85	19	1.1		3330	2070	7700	4600	9200	0.407
6210	50	90	20	1.1		3580	2370	7100	4200	8500	0.463
6211	55	100	21	1.5		4420	3000	6300	3800	7600	0.607
6212	60	110	22	1.5		5350	3690	5700	3400	6900	0.783
6213	65	120	23	1.5		5840	4090	5400	3200	6400	0.99
6214	70	125	24	1.5		6340	4490	5100	3100	6100	1.07
6215	75	130	25	1.5		6880	4920	4800	2900	5800	1.18
6216	80	140	26	2		7410	5400	4500	2700	5400	1.4
6217	85	150	28	2		8560	6310	4200	2500	5000	1.79
6218	90	160	30	2		9790	7300	3900	2400	4700	2.15
6219	95	170	32	2.1		11100	8350	3700	2200	4400	2.62
6220	100	180	34	2.1		12500	9490	3500	2100	4200	3.14
6221	105	190	36	2.1		13600	10700	3300	2000	3900	3.7
6222	110	200	38	2.1		14700	12000	3100	1800	3700	4.36
6224	120	215	40	2.1		15800	13400	2900	1700	3400	5.15
6226	130	230	40	3		17000	14900	2700	1600	3200	5.82
6228	140	250	42	3		17000	15300	2400	1500	2900	7.45
6230	150	270	45	3		18000	17100	2200	-	2700	9.41
6232	160	290	48	3		18900	19000	2100	-	2500	14.3
6234	170	310	52	4		21700	22800	1900	-	2300	17.5
6236	180	320	52	4		23200	24600	1800	-	2200	18.3
